Navimow H230E Robotic Lawn Mower

Navimow H230E – Maximum Capacity for Extra Large Lawns

The Navimow H230E is the most powerful model in the H series, engineered for very large and demanding gardens. With advanced EFLS™ LiDAR+ navigation, wire free operation and high daily mowing capacity, it delivers professional level, fully autonomous lawn care with minimal user intervention.

1.    Advanced LiDAR+ Navigation for Ultimate Stability
EFLS™ LiDAR+ fuses LiDAR, Network RTK and vision to ensure highly precise, stable navigation – even in complex layouts and challenging signal conditions.

2.    True Wire Free Installation with Auto Mapping
No boundary wires and no antennas required. Automatic mapping allows fast setup and effortless daily operation.

3.    Smart VisionFence™ Obstacle Avoidance
LiDAR enhanced VisionFence™ recognises over 200 object types, ensuring safe mowing around people, pets and garden obstacles.

4.    Maximum Capacity for Very Large Gardens
Designed to maintain lawns up to 3,000 m², with long runtime and outstanding daily coverage for efficient large area mowing.

5.    Durable, Weather Adaptive Professional Design
With IP66 protection, rain sensor and weather adaptive scheduling, the H230E is built for reliable performance in demanding outdoor environments.

Technical Data – Navimow H230E
•    Recommended Mowing Area: 3,000 m²
•    Locating System: EFLS™ LiDAR+ (LiDAR + NRTK + Vision)
•    Object Detection System: VisionFence™ (140° RGB Camera + LiDAR)
•    Driving Engine: 2 Rear Wheel Drive
•    Noise Level: 60 dB(A)
•    Protection Level: IP66
•    Weather Adaptive: Weather Forecast + Rain Sensor
•    Maximum Slope Ability: 45% (24°)
•    Antenna Installation Request: No
•    Auto Mapping: Yes
•    Auto Recharge: Yes
•    Vertical Passing Ability: 3 cm
•    Multi zone Management: Yes (up to 30 zones)
•    3D / GeoSketch: Yes
•    Signal Enhancement Antenna: No

Battery & Performance
•    Battery Capacity: 10 Ah
•    Charging Time: 120 minutes
•    Full Charge Mowing Time: 220 minutes
•    Mowing Area per Charge: 770 m²
•    Continuous Mowing Area per Day (24 h): 3,800 m²
•    Cutting Speed: Not specified

Cutting System
•    Cutting Height: 2–7 cm
•    Cutting Height Adjustment: Automatic
•    Cutting Width: 22 cm
