Navimow X420E Robotic Lawn Mower

Navimow X420E (Black) – Ultimate All Terrain Performance for Large Lawns

The Navimow X420E (Black) is engineered for large and demanding lawns where extreme slope handling, precision navigation and rugged durability are essential. Featuring EFLS™ NRTK with 360° vision, powerful 4 wheel drive and advanced obstacle avoidance, it delivers professional grade, wire free lawn care in the toughest conditions.

1.    Extreme Slope & All Terrain Capability
With powerful 4WD and dual independent steering motors, the X420E conquers slopes up to 84% (40°) and handles uneven terrain with ease.

2.    EFLS™ NRTK with 360° Vision Precision
Combining Network RTK, 360° RGB vision and VIO technology, the X420E delivers ultra stable and accurate navigation without boundary wires.

3.    360° VisionFence™ Obstacle Avoidance
Advanced VisionFence™ with RGB + ToF technology provides full surround obstacle detection for safe operation around people, pets and objects.

4.    Wire Free Auto Mapping with Real Scene Control
Automatic mapping and GeoSketch™ enable realistic yard visualisation and easy boundary editing directly in the app.

5.    Rugged, Weather Adaptive Professional Design
With IP66 protection, a new rain sensor and weather adaptive operation, the X420E is built for reliable, year round outdoor use.

Technical Data – Navimow X420E (Black)
•    Recommended Mowing Area: 2,000 m²
•    Locating System: EFLS™ NRTK (NRTK + 360° RGB Vision + VIO)
•    Object Detection System: VisionFence™ (360° RGB Camera + ToF)
•    Driving Engine: 4WD with dual independent steering motors
•    Noise Level: 68 dB(A)
•    Protection Level: IP66
•    Weather Adaptive: Weather Forecast + New Rain Sensor
•    Maximum Slope Ability: 84% (40°)
•    Antenna Installation Request: Optional
•    Auto Mapping: Yes (Auto Mapping)
•    Auto Recharge: Yes
•    Vertical Passing Ability: 7 cm (up to 15 cm on gentle slopes)
•    Multi zone Management: Yes
•    3D / GeoSketch: Yes
•    Signal Enhancement Antenna: Yes

Battery & Performance
•    Battery Capacity: 10 Ah
•    Charging Time: 75 minutes
•    Full Charge Mowing Time: 90 minutes
•    Mowing Area per Charge: 675 m²
•    Continuous Mowing Area per Day (24 h): 2,000 m² (in approx. 8 hours)
•    Cutting Speed: Not specified

Cutting System
•    Cutting Height: 2–9.5 cm
•    Cutting Height Adjustment: Automatic
•    Cutting Width: 43 cm
